5.15 Setup of the FUNCTION SETUP Menu
61
Setting “RM2 FUNC”
Set the function of the REMOTE 2 terminal.
1
Press “v” or “V” to move the cursor on “RM2
FUNC.”
Characters “RM2 FUNC” are displayed in green
when the cursor is positioned on this item.
2
Press “b” or “B” to select from among the settings
shown in Table 5.6.
The selected setting is displayed in green on the
monitor.
Setting “CLEAR”
Set the operation activated with the CLEAR button on
the front panel.
1
Press “v” or “V” to move the cursor on “CLEAR.”
Characters “CLEAR” are displayed in green when
the cursor is positioned on this item.
2
Press “b” or “B” to select one of settings “ALL,”
“PAGE,” “PART” and “OFF.”
The selected setting is displayed in green on the
monitor.
Setting “STORE IMAGE”
Store or restore all of the images stored in memory pages
and the current setup of this instrument when any
trouble, such as paper jamming, occurs.
1
Press “v” or “V” to move the cursor on “STORE
IMAGE.”
Characters “STORE IMATGE” are displayed in
green when the cursor is positioned on this item.
2
Press “b” or “B” to select either “STORE” or
“RESTOR..”
The selected setting is displayed in green on the
monitor.
To return to the PRINTER SETUP menu
Press “v” or “V” to move the cursor on “PRN SETUP,”
and press “B.”
Ta bl e 5 .6
Setting Function
CAPTURE Captures an image.
PRINT Prints the picture.
C&PRINT Captures and prints a picture.
CYCLIC-C Stores images cyclically in the memory,
and feeds the page after capturing the
image of the final pointer.
CAP-STOP Stores images cyclically in the memory,
feeds the page after capturing the image
of the final pointer, and stops at the final
pointer of the last page.
BACK-SP Moves the pointer by one space
backward.
POINTER+ Moves the pointer by one space
forward.
STOP Stops printing.
CAP/SRC When displaying the source image on
the monitor, the source image is
captured.
When displaying the memory image on
the monitor, display is switched into the
source image.
CPS/S PAGE When displaying the source image on
the monitor, the source image is
captured, and the page is fed in case of
pointer is final.
When displaying the memory image on
the monitor, display is switched into the
source image.
PRINT&PAGE Prints and feeds the page.
SRC&CAP ON : Switches the monitor display
image to the source image.
OFF : Captures an image.
SRC&C PAGE ON : Switches the monitor display
image to the Source image.
OFF : Captures an image. Feed the page
after capturing the image of the
final pointer.
ALL : Clears all of the stored images.
PAGE : Clears the images as each memory page.
PART : Clears the image in the position pointed by
the pointer.
OFF : No operation.
STORE : Stores all images and the current setup of
this instrument in the internal memory.
RESTOR. : Restores the images and the current
setup of this instrument stored in the internal
memory.
