OEV262H
Appendix
Specifications
42
Specifications
Item Specifications
performance
Panel a-Si TFT Active Matrix
LCD
Picture size
(diagonal)
660.9 mm (26.0 inches)
Effective picture
size (H × V)
Approx. 576 × 324 mm
(22
3
/
4
× 12
7
/
8
inches)
Resolution (H × V) 1920 × 1080 pixels (Full
HD)
Aspect 16:9
Pixel efficiency 99.99%
Colors Approx. 1,073,741,824
colors
Viewing angle
(panel
specification)
89°/89°/89°/89° (typical)
(up/down/left/right
contrast > 10:1)
Input Composite input
(NTSC/PAL)
connector
BNC type (×1)
1 Vp-p ± 3 dB sync
negative
Y/C input
connector
4-pin mini-DIN (×1)
Y: 1 Vp-p ± 3 dB sync
negative
C: 0.286 Vp-p ± 3 dB
(NTSC burst signal
level)
0.3 Vp-p ± 3 dB (PAL
burst signal level)
HD15 input
connector (when
inputting the PC
signal)
D-sub 15-pin (×1)
R/G/B: 0.7 Vp-p,
positive (Sync On Green,
0.3 Vp-p sync negative)
Sync: TTL level (polarity
free, H/V separate sync)
Plug & Play function:
corresponds to DDC2B
HD15 input
connector (when
using the optional
HD15-BNC4P
cable)
• RGB/Component
input
BNC type (×3)
RGB: 0.7 Vp-p ± 3
dB (Sync On Green,
0.3 Vp-p sync
negative)
Component: 0.7 Vp-p
± 3 dB (75%
chrominance standard
color bar signal)
• External synchronized
input
BNC type (×1)
0.3 Vp-p to 4.0 Vp-p
± bipolarity ternary or
negative polarity
binary
DVI input
connector
DVI-I connector (×2)
• When using a DVI-
DVI cable
TMDS single link
• When using a DVI-
HD15 cable
R/G/B: 0.7 Vp-p
positive (Sync On
Green, 0.3 Vp-p sync
negative)
Sync: TTL level
(polarity free, H/V
separate sync)
Plug & Play function:
corresponds to
DDC2B
SDI input
connector
BNC type (×2)
AUX IN connector
(SDI signal)
BNC type (×1)
Parallel remote Modular connector 8-pin
(×1)
Serial remote D-sub 9-pin (RS-232C)
(×1)
DC IN connector DC5V/24V (output
impedance 0.05 ohmsor
less)
Output Composite output
connector
BNC type (×1)
Loop-through, with 75
ohms automatic terminal
function
Y/C output
connector
4-pin mini-DIN (×1)
Active-through
HD15 output
connector
D-sub 15-pin (×1)
Active-through
DVI output
connector
DVI-I connector (×2)
Active-through
SDI output
connector
BNC type (×2)
Active-through
CLONE OUT
connector (SDI
signal)
BNC type (×1)
Active-through
5 V output
connector
HR10A connector
