OEV262H
Appendix
Specifications
43
General Dimensions 626.8 (W) × 395.2 (H) ×
79.6 (D) mm (24
3
/
4
(W)
× 15
5
/
8
(H) × 3
1
/
4
(D)
inches)
Mass Approx. 7.8 kg (17 lb 3
oz)
Power LCD monitor
(OEV262H)
AC 100 V-240 V, 50/60
Hz, 0.96 A-0.47 A
DC IN: 24 V 3.6 A 5 V
0.03 A (Supplied from
AC adapter)
AC adapter (Sony, AC-
110MD) (optional)
AC 100 V-240 V, 50/60
Hz, 1.53 A-0.58 A
DC OUT: 24 V 5.0 A
5 V 0.060 A
Power consumption Maximum: 112 VA
Operating
conditions
Temperature
10 °C to 40 °C (32 °F to
95 °F)
Humidity
30% to 85% (no
condensation)
Pressure
700 hPa to 1060 hPa
Storage and
transport condition
Temperature
–20 °C to +60 °C (–4 °F
to +140 °F)
Humidity
10% to 90%
Pressure
700 hPa to 1060 hPa
Accessories
supplied
AC power cord (1)
Plug holder for the
supplied AC power cord
(1)
Cord holder (1)
Screw for the cord holder
(1)
Screws for VESA mount
(6)
Instructions for Use (1)
Optional
accessories
Monitor stand
SU-560
AC adapter
AC-110MD
Medical
Specifications
Protection against electric shock:
Class I
Protection against harmful ingress of water:
Ordinary
Degree of safety in the presence of a
flammable anesthetic mixture with air or with
oxygen or nitrous oxide:
Not suitable for use in the presence of a
flammable anesthetic mixture with air or with
oxygen or nitrous oxide
Mode of operation:
Continuous
Item Specifications
Year of
manufacture
Indication The year of manufacture
is the second digit
of the serial number.
Ex. 74
01234
EMC Applied standard IEC 60601-1-2: 2001
IEC 60601-1-2: 2007
This instrument complies
with the EMC standard
for medical electrical
equipment, edition 2
(IEC 60601-1-2: 2001)
and edition 3 (IEC
60601-1-2: 2007).
However, when
connecting to an
instrument that complies
with the EMC standard
for medical electrical
equipment, edition 1
(IEC 60601-1-2: 1993),
the whole system
complies with edition 1.
Emission standard CISPR 11 of emission:
Group 1, Class A
Item Specifications
