OEV262H
Appendix
Specifications
44
Pin assignment
PARALLEL REMOTE connector
Modular connector
(8-pin)
You can allocate functions using the Remote menu (see
page 31).
Wiring required to use the Remote Control
Connect the function you want to use with a remote
control to the ground (Pin 5).
SERIAL REMOTE (RS-232C) connector
D-sub 9-pin, female
Available signal formats
Analog signal
Digital signal
* The frame rate is also compatible with 1/1.001.
Pin number Functions
1 Function that is displayed on OSD.
2 Function that is displayed on OSD.
3 Function that is displayed on OSD.
4 Function that is displayed on OSD.
5 GND
6 Function that is displayed on OSD.
7 Function that is displayed on OSD.
8 Function that is displayed on OSD.
Pin number Signal
1 NC
2 TX
3 RX
4 NC
5 GND
6 DTR
7 CTS
8 RTS
9NC
Signal
format
Input connector
COMPOSITE
Y/C HD15
COMPONENT
RGB
NTSC a a – –
PAL a a – –
480/59.94i – – a a
480/60i – – a a
480/60p – – a a
576/50i – – a a
576/50p – – a a
720/59.94p – – a a
720/60p – – a a
720/50p – – a a
1080/59.94i – – a a
1080/60i – – a a
1080/50i – – a a
Signal
format
Input connector
SDI 1
SDI 2
AUX
(SDI)
DVI 1
DVI 2
3G/HD/SD-SDI DVI-D
480/59.94i a a –
480/60p – – a
575/50i a a –
576/50p – – a
720/59.94p a a a
720/60p a a a
720/50p a a a
1080/59.94i a a a
1080/60i a a a
1080/50i a a a
1080/59.94p
*
aaa
1080/60p
*
aaa
1080/50p a a a
