OEV262H
Appendix
Specifications
45
Analog PC signal
VESA DMT
VESA CVT
Resolution Dot clock
[MHz]
fH
[kHz]
fV
[Hz]
Sync. polarity
Horizontal Vertical
640 × 480 60 Hz 25.175 31.469 59.940 Negative Negative
800 × 600 56 Hz 36.000 35.156 56.250 Positive Positive
800 × 600 60 Hz 40.000 37.879 60.317 Positive Positive
800 × 600 72 Hz 50.000 48.077 72.188 Positive Positive
800 × 600 75 Hz 49.500 46.875 75.000 Positive Positive
800 × 600 85 Hz 56.250 53.674 85.061 Positive Positive
1024 × 768 60 Hz 65.000 48.363 60.004 Negative Negative
1024 × 768 70 Hz 75.000 56.476 70.069 Negative Negative
1024 × 768 75 Hz 78.750 60.023 75.029 Positive Positive
1024 × 768 85 Hz 94.500 68.677 84.997 Positive Positive
1152 × 864 75 Hz 108.000 67.500 75.000 Positive Positive
1280 × 960 60 Hz 108.000 60.000 60.000 Positive Positive
1280 × 1024 60 Hz 108.000 63.981 60.020 Positive Positive
1600 × 1200 60 Hz 162.000 75.000 60.000 Positive Positive
Resolution Dot clock
[MHz]
fH
[kHz]
fV
[Hz]
Sync. polarity
Horizontal Vertical
640 × 480 60 Hz 23.625 29.531 59.780 Positive Negative
800 × 600 60 Hz 35.500 36.979 59.837 Positive Negative
1024 × 768 60 Hz 56.000 47.297 59.870 Positive Negative
1280 × 960 60 Hz 85.250 59.201 59.920 Positive Negative
1600 × 1200 50 Hz 132.375 61.742 49.994 Negative Positive
1600 × 1200 60 Hz 130.375 74.077 59.981 Positive Negative
1360 × 768 50 Hz 69.500 39.489 49.922 Negative Positive
1360 × 768 60 Hz 84.625 47.649 59.936 Negative Positive
1360 × 768 60 Hz 72.000 47.368 59.960 Positive Negative
1920 × 1080 50 Hz 141.375 55.572 49.975 Negative Positive
1920 × 1080 60 Hz 138.625 66.647 59.988 Positive Negative
1920 × 1200 50 Hz 158.000 61.719 49.975 Negative Positive
1920 × 1200 60 Hz 154.125 74.099 59.999 Positive Negative
1280 × 1024 60 Hz 91.000 63.194 59.957 Positive Negative
1280 × 768 50 Hz 65.125 39.518 49.959 Negative Positive
1280 × 768 60 Hz 80.125 47.693 59.992 Negative Positive
