Operation
MOBILE WORKSTATION WM-DP1
22
Chapter 6 Operation
6.1 Operation
WARNING
• The WM-DP1 should be used in accordance with the following.
Otherwise, the workstation will be ‘top heavy’ and may lose stability and
topple, causing equipment damage and/or personal injury.
- Two MAJ-181 restrictors are supplied which must be fitted to
MAJ-181 LCD monitor arm(s) if used (refer to section 4.8).
- LCD monitor arms and monitors should be installed after all
other equipment is installed on an appropriate place on the
workstation.
- LCD monitor arms should not be installed or used to the rear
of the workstation, see Figure 2.1.
- Confirm that the workstation does not lose stability when the
monitor arm is extended. If the workstation looks unstable,
relocate heavy equipment from the upper shelf to the bottom
shelf.
CAUTION
• Place the mobile workstation on a flat level surface and lock the castor
brakes.
• Confirm that any mounted instruments function normally before using
the system on a patient.
1. Plug the power cord of the mobile workstation into a hospital-grade power outlet.
2. Confirm that the power indicator on the remote switch lights yellow.
3. When the remote switch is ON, confirm that the power indicator lights green.
4. For use of Optional accessories, please refer to each accessory instruction manual.
5. During use, do not position LCD monitor arms to the rear as shown below. Otherwise, the
workstation may lose stability and topple, causing equipment damage and/or personal injury.
To Next Page
