Symbols
MOBILE WORKSTATION WM-DP1
8
Chapter 3 Symbols
The following symbols are used on the separation transformer
NOTE
MAJ-175 (220-240V) is shown. Other versions are similar.
Refer to instructions Potential equalisation terminal
Input Output
Not exceeding
T
a
=40°C
Maximum ambient
temperature
Standby position Fuse (output)
Output ON position Remote switch
Non-inherently short circuit
proof separation transformer
Class B
Insulation temperature rating
of transformer according to
IEC 60085:2004
Unit complies with relevant
European directives
(MAJ-175 only)
Disposal conditions - see End
of Life (Chapter 12) (MAJ-175
only)
View of the separation transformer rear panel
