COMPONENTS CODE
42
PART
CODE
PRODUCT
CATEGORIES
MATERIALS
PART CODE
FAMILY
VERSION
SEAL
TYPE
1 = Pumps
2 = Spare parts - components
3 = Pre-assembling
4 = Commercial parts
5 = Semi-finished parts
6 = Raw materials - meltings
12345678
001 Bearing supports and other details
3 Rotor cases
004 Shafts
etc. see list
A = AISI 304 stainless steel
B = AISI 316 stainless steel
C = AISI 420 stainless steel
etc. see list
Example = bearing support B220 cast iron cod. 2001G002
ROTOR CASES CODE
CONNECTION
PARTS
MATERIALS
2 = Finished component
5 = Semi-finished component
6 = Raw melted component
3 = Family of belonging
0 = Standard
1 = Standard heated
2 = Aseptic
3 = Aseptic heated
6 = Enlarged inlet port
7 = Heated/Enlarged inlet port
0 = UM and mechanical seals
1 = Packing glands
9 = Special
0 = BSP male gas thread
1 = PN 16 UNI 2278 flanges
2 = DIN 11851
3 = SMS
4 = RJT (BS)
5 = IDF - ISS
6 = Tri - Clamp
7 = Female gas thread
8 = Oenological
9 = Special
B - H - I - J - R
PROGRESSIVE NUMERATION ACCORDING TO THE SIZES
PROGRESSIVE NUMERATION ACCORDING TO
THE SIZES
Example = rotor case with mech. seals - DIN - Heated - AISI 316 SS - B430 cod. 23102 B 07
1 2 3 4 5 6 7 8
