OMAC B430 - Parts List - Spare Parts Code

49
B100 PART LIST - SPARE PARTS CODE
Key No. Description
1
2
3
4
5
6
7
8
9
10
11
12
13
15
17
18
19
20
21
25
26
29
30
40
41
42
43
44
45
47
48
50
51
52
55
200
201
210
218
240
241
242
243
244
280
281
283
288
295
Materials No. REQ. PART No.
Bearing Housing G25 Cast Iron 1 2001G007
Gear cover Aluminium 1 2001L037
Standard driving shaft Aisi 316 L S.S. 1 2004B061
Standard driven shaft Aisi 316 L S.S. 1 2004B062
Fixed gear 38NCD4 1 2008M013
Adjustable gear 38NCD4 1 2008M017
Adjustable gear bush 38NCD4 1 2008M038
M4x10 TE screw Iron 6 410F04X10
Split ring Iron 2 421F371
Din 6319 type G d=6x17 plane washer Iron 4 412F06G17
Axial adjustement spacer Iron 2 2014M030
M6x35 TCEI screw Aisi 304 S.S. 4 411A06X35
M6x12 TCEI screw Iron 4 411F06X12Z
Gear cover seal Fibre 1 404T100
18x30x7 oil seal ring N.B.R. 1 403Y18307D
25x37x7 oil seal ring N.B.R. 2 403Y25377D
6x6x18 Key Iron 2 418F06x18
6x6x30 Key AISI 304 S.S. 1 418A06x30
M20x1 gear ring nut Iron 2 415F20AUT
1/4” oil cap vent Brass 1 407L14S
1/4" oil cap Aluminium 1 407L14T
HK 3020 front bearing and bush 2 2019M020
NATB 5904 rear bearing 2 406 FNATB5904
Rotor case AISI 316 L S.S. 1 23….B14
316 S.S. gear rotor ST AISI 316 L S.S. 2 2005B086
316 S.S2 lobe ST AISI 316 L S.S. 2 2005B089
Rubber coated 316 S.S. 5 lobe AISI 316 S.S. + Rubber 2 2005B098
S.S. anti-seizure alloy gear rotor Acteon 2 2005&086
S.S. anti-seizure alloy 2 lobe Acteon 2 2005&089
Locking nut for rotor AISI 316 L S.S. 2 2004B107
3075 O’ring N.B.R. 2 404T3075
Standard end cover AISI 316 L S.S. 1 2006B007
4337 cover o’ring N.B.R. 1 404T4337
M6x80 front stud AISI 304 S.S. 4 419A06X80
d=8x20 front pin AISI 304 S.S. 2 417A08X16
2056 O’ring N.B.R. 2 404T2056
M6 cap nut AISI 304 S.S. 4 414A06
UNI 5588 nut AISI 304 S.S. 2 413A06
Plane washer Iron 6 412F04
Retainer pin AISI 304 S.S. 2 2014B200
Mechanical seal UNITEN 7K-X7XZ7.HX
AISI 316 S.S./CarbonN/EPDM 2 4U020U7KXZ7
Mechanical seal UNITEN 7K-XYXZY.HX
AISI 316 S.S./Carbon/Viton 2 4U020U7KXZY
Mechanical seal UNITEN 7K-XFXZ5.HX
AISI 316 S.S./Carbon/PTFE 2 4U020U7KXZ5
Mechanical seal UNITEN 7K-X73Z7.HX
Tung. Carbide/Carbon/EPDM 2 4U020U7K3Z7
Mechanical seal UNITEN 7K-XY3ZY.HX
Tung. Carbide/Carbon/Viton 2 4U020U7K3ZY
Mechanical seal UNITEN 7K-XF3Z5.HX
Tung. Carbide/Carbon/PTFE 2 4U020U7K3Z5
Mechanical seal UNITEN 7K-X7337.HX
Tung. Carbide/Tung.Carb/EPDM 2 4U020U7K337
Mechanical seal UNITEN 7K-XY33Y.HX
Tung. Carbide/Tung.Carb/Viton 2 4U020U7K33Y
Mechanical seal UNITEN 7K-XF335.HX
Tung. Carbide/Tung. Carb./PTFE 2 4U020U7K335
Mechanical seal UNITEN 7K-XYDKKY.HX
Silicon Carbide/Sil. Carb./Viton 2 4U020U7KKKY
Balancing ring for seal 304 AISI S.S. 2 2014B015
M6x12 TE screw 304 AISI S.S. 4 410A06X12
35x25x5 seal ring Viton 4 402V35255
35x25x5 seal ring EPDM 4 402U35255
S1 polymer lip seal polymer 2 402Q35256
Seal ring bush 316 L Aisi S.S. 2 2004B171
3081 bush o’ring N.B.R. 2 404T3081
M5x6 screw 304 AISI S.S. 6 420A05X05
Seal ring support 316 L AISI S.S. 2 2014B058
S1 lip seal support 304 AISI S.S. 2 2014B065
Ptfe packing ring kit PTFE 1 205P25355
Staffing box - S1 seal bush 316 L AISI S.S. 2 2004B170
Screw 304 AISI S.S. 6 420A05X05
Register 316 L AISI S.S. 2 2014B108
Spacer 304 AISI S.S. 2 2014B045
