PART 5
FACTORY PRESET VALUES
Table 5.1 Factory preset value
MENU ITEMS FACTORY PRESET VALUES NOTES
Set Point 1 (SP1) 000.0
Set Point 2 (SP2) 000.0
Input:
Input Type (INPT) 0 TO 100 MV (0-0.1)
Ratiometric Operation (RTIO) Enable (ENBL)
Display Resolution (RESO) Low (LO)
b
Button Peak (PEAK)
Reading Configuration (RDG):
Decimal Point (DEC.P) FFF.F
Linearization Points (L.PNt) 0002
Filter Value (FLTR) 0004
Input/Reading (IN.RD) 0-100 mV = 0-9999
Scale and Offset
Alarm 1 & 2
:
Alarm 1 (ALR1), Alarm 2 (ALR2) Disable (DSBL)
Absolute/Deviation (ABSO/DEV) Absolute (ABSO)
Latch/Unlatch (LTCH/UNLT) Unlatch (UNLT)
Contact Closure (CT.CL) Normally Open (N.O.)
Active (ACTV) Above (ABOV)
Alarm At Power On (A.P.ON) Disable (DSBL) Alarm 1 only
Alarm Low (ALR.L) -100.0
Alarm High (ALR.H) 400.0
Setpoint Deviation:
Setpoint Deviation Disable (DSBL)
ID
:
ID Value 0000
Full ID (FULL) Disable (DSBL)
Set Point ID (ID.SP) Disable (DSBL)
To Next Page
