Section 4 - RS-232 or RS-485 Communication (Optional)
4.1 Communication Cable Connections
Your controller unit has been factory pre-wired and configured for ease of use
with an RJ12 rear panel connection that will requires no additional wiring.
An interface cable, Part No. DB9-R12 is included with your unit for easy
connection between your benchtop controller and PC.
Figure 4. Internal Wiring - Benchtop Controller
4.2 Communication Software
Benchtop controllers with the –C24 option come complete with
communication software for configuration. The software is designed to
interface with your benchtop controller when the optional communication
hardware has been factory installed in your unit.
Note: The iSeries configuration software is Windows
®
95/98/2000/NT/XP
compatible.
4.3 Communication Settings and Programming
Refer to the Software Communication Manual (M3397) for factory default
settings and for making changes to the communication settings and
programming.
7
RS-232 or RS-485 Comunication (Optional)
4
INTERNAL WIRING
BENCHT
OP CONTROLLER
CONTROLLER - REAR
GREEN
REAR PA NEL
RJ12 CONNECTOR
RJ12 TO DB-9 ADAPTER
1.8 METERS (6 FEET)
CONNECT TO PC
TX
RX
GND
RED
BLACK
6
1
9
5
1 2 3 4 5 6 8 7 9
10
87654321
