Section 5.3 - Clear Alarms
Any active, latched alarm is cleared.
Section 5.4 - Display Alarm Values
Displays the Alarm Value for the current zone and stops scanning.
The Main display shows the Alarm value. The Zone display shows
the zone.
Increments the Zone number and displays the next
Alarm Value.
Switches between HI and LO Alarm Values. The Function
display shows 3 when displaying Low values and 4 when
displaying High Values.
Return to Run Mode
Section 5.5 - Function Select Mode
Enter Function Select Mode from Run Mode
Section 5.6 - Reset Defaults
Hold all 3 buttons down for 5 seconds to reset unit to Factory
Defaults. The unit will reboot and return to Run Mode.
Section 5.2 - Lock Zones
Symbol Description
The display stops cycling thru each display. The currently selected
zone information will be continuously updated on the display. Note
that all active zones continue to be read and any alarm conditions
will activate the enabled alarm relays.
The Lock option is released and the value display will cycle thru all
active zones.
