Omega DP612A User Manual

Modbus Register Assignments
7
Index Mnemonic Type Access Description
0x0100 40256 Temperature Zone 1 F R Zone 1 Process Value
0x0102 40258 Temperature Zone 2 F R Zone 2 Process Value
0x0104 40260 Temperature Zone 3 F R Zone 3 Process Value
0x0106 40262 Temperature Zone 4 F R Zone 4 Process Value
0x0108 40264 Temperature Zone 5 F R Zone 5 Process Value
0x010a 40266 Temperature Zone 6 F R Zone 6 Process Value
0x010c 40268 Temperature Zone 7 F R Zone 7 Process Value
0x010e 40270 Temperature Zone 8 F R Zone 8 Process Value
0x0110 40272 Temperature Zone 9 F R Zone 9 Process Value
0x0112 40274 Temperature Zone 10 F R Zone 10 Process Value
0x0114 40276 Temperature Zone 11 F R Zone 11 Process Value
0x0116 40278 Temperature Zone 12 F R Zone 12 Process Value
Section 7.2 - Temperature Registers
Index Mnemonic Type Access Description
0x0180 40384 Sensor Status Zone 1 R R Zone 1 Sensor status
0x0181 40385 Sensor Status Zone 2 R R Zone 2 Sensor status
0x0182 40386 Sensor Status Zone 3 R R Zone 3 Sensor status
0x0183 40387 Sensor Status Zone 4 R R Zone 4 Sensor status
0x0184 40388 Sensor Status Zone 5 R R Zone 5 Sensor status
0x0185 40389 Sensor Status Zone 6 R R Zone 6 Sensor status
0x0186 40390 Sensor Status Zone 7 R R Zone 7 Sensor status
0x0187 40391 Sensor Status Zone 8 R R Zone 8 Sensor status
0x0188 40392 Sensor Status Zone 9 R R Zone 9 Sensor status
0x0189 40393 Sensor Status Zone 10 R R Zone 10 Sensor status
0x018a 40394 Sensor Status Zone 11 R R Zone 11 Sensor status
0x018b 40395 Sensor Status Zone 12 R R Zone 12 Sensor status
0x018c
40396 Sensor Status Bitmap R R Sensor status bitmap for all zones
0x018d
40397 Alarm Status Bitmap R R Alarm status bitmap for all zones
Section 7.3 - Status Registers
Table 12 - Temperature Registers
Table 13 - Sensor Status Registers
