Omega FMA 5400A - Appendix 3 Dimensional Drawings; Appendix

42
APPENDIX 3
DIMENSIONAL DRAWINGS
6.29
(159.8)
4.27
(108.5)
3.66
(93.0)
4.61
(117.1)
5.72 (145.3)
1.00 (25.4)
1.13 (28.6)
0.50 (12.7)
1.00
(25.4)
0.50
(12.7)
0.53
(13.5)
2.69
(68.3)
0.69 (17.5)
0.16 (4.0)
6-32 UNC - 2B 0.13
0.95 (24.1)
2.38 (60.4)
1.25 (31.8)

SERIES MAX. FLOW 10 L/min MASS FLOW CONTROLLER
NOTE: OMEGA
®
reserves the right to change designs and dimensions at its sole discretion at any time
without notice. For certified dimensions please contact OMEGA
®
.
