Omega OS550A - Plastic Housing Dimensions

2-3
Installing the Infrared Thermometer
2
131.3
(5.17) TYP.
120.6
(4.75) TYP.
Ø 4.37 (0.172) MOUNTING HOLE
(4 PLACES)
50.0
(1.97) TYP.
80.10
(3.15) TYP.
DIMENSIONS: mm (in)
Fig. 2-2. Plastic Housing Dimensions
2.3 OS550A Main Display Standard Plastic Housing Dimensions
