Specifications
7
7-2
Emissivity: 0.10 to 1.00 in 0.01 increments, set via keypad
Calculated Temperature Maximum (MAX), Minimum (MIN),
Values: Average (AVG), Differential (dIF)
Average Temp Accuracy 30 Days
Time Period
(Under Continuous Operations)
Ambient Target Temperature
Compensation: OS552A thru OS555A
set and enabled via keypad
RS-232 Output OS552A thru OS555A
set and enabled via keypad
9600 bits per second, 8 bits of data,
1 stop bit, no parity
RS-232 Cable: RJ12 to 9 pin D connector, Female
RJ12 Pin # 9 pin D connector Pin #
3 TX 2 RX
4 RX 3 TX
5 GND 5 GND
Power/Analog Output Cable: 15' long; 8-conductor, shielded 24 AWG
Sensor Head Cable 15' long; 5-conductor, shielded 24 AWG
Alarm: Set and enabled via keypad
All models: High alarm standard, with
audible and visual indication with red LED
OS552A, OS553A: Low alarm standard, with
OS554A, OS555A audible and visual indication
with red LED
Alarm Deadband 10°F (5°C)
Alarm Outputs Voltage; 100mA Drive
Data Storage: OS553A, OS554A, OS555A Up to 800 sets of
temperatures data points on command or
continuous data logging.
Dimensions:
Main Housing, Plastic: 120.6 x 80.0 x 50.8 mm (4.75 x 3.15 x 2.00")
Main Housing, Aluminum 115.0 x 90.0 x 55.5 mm (4.54 x 3.54 x 2.18")
Sensor Head: 41.1 dia. x 109.2 mm (1.62 dia. x 4.30")
Weight:
Main Electronics: 2.2 kg. (1 lb.)
Sensor Head: 1.87 kg. (0.85 lb.)
