Construction and Functioning
Figure 3-5:
15 m (50 ft) RG58
coaxial cable with SMA
connector (extension
cable for antenna)
For cases that may require an extension of the antenna cable, an optional set of
2 × 20 m (2 x 60 ft) cables is available from OMICRON.
Figure 3-6:
CMGPS connected to
antenna via 2 × 20 m
(2 x 60 ft) extension
cables.
Note: when connecting
VEHZ3003, VEHK3002
shown in figure 3-5
cannot be used
anymore.
Article number VEHK3002
Antenna
CMGPS
2 extension cables + SMA adapter (see also figure 3-7).
Article number VEHZ3003
