Field Description
Clr matrix & die
cut
Click this button to clear all matrix and die cut filled sections.
Clear all
Click this button to Clear all ignored and auto filled sections within a chosen
sector.
4. The options in the Display box are shown below:
Field Description
Normal Shows the Actual image only.
Area Type
This view shows the label using the color codes for each blemish feature.
Normal + Error
This view allows the user to see errors as they occur. The user usually uses
this screen to find the errors, and then goes to the Normal+Ignore screen to
draw the ignore sections.
Error Only
This is a tool for the operator to use in order to understand what the software
views as a difference between the Golden image and the Actual image. When
this option is selected, the image will turn black and errors will be highlighted in
white.
Golden Shows an overlay of the Golden Image over the Actual Image.
5. Click the Global copy button to replicate the setting changes in the same sector across all labels. See the
“Global Copy” section for more information.
6. Click the right arrow button.
