LVS-7500 External System Operations Manual
LVS-7500 External System Operations Manual Page 60 of 129
Field
Description
options on this page alone. This option will be grayed out when
using OCV.
Match this text To match a static (unchanging) number, select Match this text
and enter the desired string into the text box.
Match data in sector If you are using multiple sectors, you may wish to match the data
in one sector to the data in another sector. To accomplish this,
select Match data in sector and choose the desired sector from
the drop-down list of previously trained sectors.
The Majority feature looks at all sectors that are set to majority,
takes the most popular result, and then matches the sectors to
that popular result.
The At Position feature tells the software where to start reading
data within a sector.
Take the string A1234 as an example, if you change at position
to 3 then the software will only read 234.
The Global copy feature will copy the logically located sector as
compared to the original “From” and “To” sectors’ positional
relationship.
Refer to the diagram below in the “Global Copy Diagram” section.
Ascending or Descending When checking sequential data, you must select Ascending or
Descending.
• If the numbers are incrementing by a different amount, you
can select the amount to increment in the Step list box.
• If the sequence is a combination of alpha and numeric, then
select the Base numbering system.
Prompt When Run is Started
When selected, this feature allows a “Match this text” string to be
entered by the operator at the time of starting a run, allowing the
“Match To” text to be changed without allowing job editing to that
operator’s permissions.
When this option is selected the system will prompt at run time for
the “Match to” string. Enter the string in the available text field.
Note that each sector is labeled accordingly.
Match to File This feature compares the data decoded within a sector to the
data on a file created by the user. Options include:
• Duplicates allowed – The system allows for repeated data
within the same sector and/or file.
• Unique per sector – The system does not allow any repeated
data within the same sector and/or column within a file.
• Unique per job – The system does not allow any repeated
data within the same sector and/or file.
See the Match to File section below for additional details about
this feature.
Click Enter Location to select the location of the file being
matched.
Check for Duplicates Checks data for any duplicates.
Options include:
• Unique per sector – The system does not allow any repeated
data within the same sector.
• Unique per job – The system does not allow any repeated
data within the same sector or job/roll.
