Field Description
Error Display
This is a very helpful feature for the operator to analyze only the errors as they
happen. Or, the operator may choose to study one error condition at a time. This
feature is activated by clicking on the error. This causes the software to show an
image of the next error as superimposed thumbnail images. The process of
showing this error image can be performed while the system is in the Operate
condition. A series of error images are stored in the log file of each job. Thumbnails
of the actual errors can be viewed “offline”. See the Error Display section below for
more information.
Full Web Image
The image at the bottom of the Operate Screen is the entire field of view and will
update up to 10 images per second as the printer is running.
Live Reports Log
A log will appear overlaid onto the Operate Screen when the operator clicks inside a
sector. This log represents what the software sees inside this sector.
• A green box indicates a good read.
• A red box indicates an error condition has occurred.
This log can be moved to any position on the Operate Screen by left click and hold
at the very top of the log screen. To get a freeze frame of this box click on any other
non-sector part of the image. This will cause the box to stop updating. To resume
the update, just click in the desired sector. If it is no longer wanted, it can be closed
by clicking the red X (Close) box in the top right corner.
Histograms
At the top of the Operate Screen is a section for displaying a histogram for every
error condition the software is trained to analyze. It is color coded.
• Green is “good’
• Red is “bad”
Each sector “Type” will have its own graph. All sectors of a given type will be
displayed within the graph designated for that “Type”.
