Inverter Models
Rated voltage Degree of protection Max. applicable motor
capacity
Model
3-phase 200 V AC Closed wall-mounting type (equivalent to IP20)
0.1 kW 3G3JV-A2001
p
gyp (q )
0.2 kW 3G3JV-A2002
0.4 kW 3G3JV-A2004
0.75 kW 3G3JV-A2007
1.5 kW 3G3JV-A2015
2.2 kW 3G3JV-A2022
3.7 kW 3G3JV-A2037
Single-phase 200 V AC Closed wall-mounting type (equivalent to IP20)
0.1 kW 3G3JV-AB001
gp
gyp (q )
0.2 kW 3G3JV-AB002
0.4 kW 3G3JV-AB004
0.75 kW 3G3JV-AB007
1.5 kW 3G3JV-AB015
3-phase 400 V AC Closed wall-mounting type (equivalent to IP20)
0.2 kW 3G3JV-A4002
p
gyp (q )
0.4 kW 3G3JV-A4004
0.75 kW 3G3JV-A4007
1.5 kW 3G3JV-A4015
2.2 kW 3G3JV-A4022
3.7 kW 3G3JV-A4037
Explanation of Product Code
Series name:
3G3JV Series
Max. applicable motor capacity
Voltage class
Degree of protection
3-phase 200 V AC (200-V class)
Single-phase 200 V AC (200-V class)
3-phase 400 V AC (400-V class)
Panel-mounting type (IP10 or higher)/closed wall-mounting type
3G3JV-A2007
001 0.1 kW
002 0.2 kW
004 0.4 kW
007 0.75 kW
015 1.5 kW
022 2.2 kW
037 3.7 kW
