Floating-point Math Instructions Section 3-13

TANGENT

TAN

@TAN

462

Output

Required

ARC SINE

ASIN

@ASIN

463

Output

Required

ARC COSINE

ACOS

@ACOS

464

Output

Required

ARC TANGENT

ATAN

@ATAN

465

Output

Required

SQUARE ROOT

SQRT

@SQRT

466

Output

Required

Instruction

Mnemonic

Code

Symbol/Operand Function Location

Execution

condition

S: 1st source

word

R: 1st result word

TAN(462)

Calculates the tangent of a 32-bit floating-point number (in radians) and

places the result in the specified result words.

R+1 R

Source (32-bit

floating-point

data)

S+1

Result (32-bit

floating-point

data)

TAN

S: 1st source

word

R: 1st result word

ASIN(463)

Calculates the arc sine of a 32-bit floating-point number and places the result

in the specified result words. (The arc sine function is the inverse of the sine

function; it returns the angle that produces a given sine value between −1 and

1.)

R+1 R

Source (32-bit

floating-point

data)

S+1

Result (32-bit

floating-point

data)

SIN

-1

S: 1st source

word

R: 1st result word

ACOS(464)

Calculates the arc cosine of a 32-bit floating-point number and places the

result in the specified result words. (The arc cosine function is the inverse of

the cosine function; it returns the angle that produces a given cosine value

between −1 and 1.)

R+1 R

Source (32-bit

floating-point

data)

S+1

Result (32-bit

floating-point

data)

COS

-1

S: 1st source

word

R: 1st result word

ATAN(465)

Calculates the arc tangent of a 32-bit floating-point number and places the

result in the specified result words. (The arc tangent function is the inverse of

the tangent function; it returns the angle that produces a given tangent value.)

R+1

Source (32-bit

floating-point

data)

S+1

Result (32-bit

floating-point

data)

TAN

-1

S: 1st source

word

R: 1st result word

SQRT(466)

Calculates the square root of a 32-bit floating-point number and places the

result in the specified result words.

R+1

Source (32-bit

floating-point

data)

S+1

Result (32-bit

floating-point

data)
