Omron CJ1M-CPU series Programming Manual

142
Block Programming Instructions Section 3-30
COUNTER WAIT
CNTW
814
(BCD)
Block program
Required
CNTWX
817
(Binary)
(CS1-H, CJ1-H,
CJ1M only)
CNTWX(817)
N
SV
N: Counter
number
SV: Set value
I: Count input
HIGH-SPEED
TIMER WAIT
TMHW
815
(BCD)
Block program
Required
TMHWX
818
(Binary)
(CS1-H, CJ1-H,
CJ1M only
TMHWX(818)
N
SV
N: Timer number
SV: Set value
Instruction
Mnemonic
Code
Symbol/Operand Function Location
Execution
condition
CNTW(814)
N
SV
N: Counter
number
SV: Set value
I: Count input
"B" executed.
"
A"
executed.
SV
preset.
C
"C" executed.
Time elapsed.
"C"
executed.
"C"
executed.
Delays execution of the rest of the block program until the specified count
has been achieved. Execution will be continued from the next instruction
after CNTW(814) when the counter counts out.
TMHW(815)
N
SV
N: Timer number
SV: Set value
"A"
executed.
Time elapsed.
"B" executed.
C
"C" executed.
BEND
SV
preset.
Delays execution of the rest of the block program until the specified time has
elapsed. Execution will be continued from the next instruction after
TMHW(815) when the timer times out. SV = 0 to 99.99 s

Omron CJ1M-CPU series Specifications

General

Series	CJ1M
Program Memory	Flash Memory
Power Supply Voltage	24V DC
Operating Temperature	0 to 55°C
Type	Programmable Controller
CPU Type	CPU11, CPU12, CPU13, CPU21, CPU22, CPU23
Data Memory	SRAM
Data Memory Capacity	32K words (CJ1M-CPU11/12/13), 64K words (CJ1M-CPU21/22/23)
Instruction Execution Time (Basic Instructions)	0.1 μs (LD instruction)
Instruction Set	Basic instructions, advanced instructions
Programming Language	Ladder Diagram, Structured Text, Function Block Diagram
Communication Ports	RS-232C
Expansion Slots	Up to 3
Mounting	DIN rail mounting
Storage Temperature	-25 to 70°C
Dimensions	90 x 90 x 70 mm
Weight	Approx. 200g (0.44 lb)
Number of Instructions	Over 400 instructions
