74
Sequence Output Instructions Section 3-2
SINGLE BIT SET
(CS1-H, CJ1-H,
or CJ1M only)
SETB
@SETB
!SETB
532
SETB(532) turns ON the specified bit in the specified word when the execu-
tion condition is ON.
Unlike the SET instruction, SETB(532) can be used to set a bit in a DM or EM
word.
Output
Required
SINGLE BIT
RESET
(CS1-H, CJ1-H,
or CJ1M only)
RSTB
@RSTB
!RSTB
533
RSTB(533) turns OFF the specified bit in the specified word when the execu-
tion condition is ON.
Unlike the RSET instruction, RSTB(533) can be used to reset a bit in a DM or
EM word.
Output
Required
SINGLE BIT
OUTPUT
(CS1-H, CJ1-H,
or CJ1M only)
OUTB
@OUTB
!OUTB
534
OUTB(534) outputs the result (execution condition) of the logical processing
to the specified bit.
Unlike the OUT instruction, OUTB(534) can be used to control a bit in a DM
or EM word.
Output
Required
Instruction
Mnemonic
Code
Symbol/Operand Function Location
Execution
condition
D: Word address
N: Bit number
SETB(532)
D
N
D: Word address
N: Bit number
RSTB(533)
D
N
D: Word address
N: Bit number
OUTB(534)
D
N
To Next Page
