83
HIGH-SPEED COUNTER PV READ: PRV(881) Section 5-2
C = 0023 hex: 100-ms sampling method for high frequency (supported
only by CJ1M CPU Units Ver. 3.0 or later)
C = 0033 hex: 1-s sampling method for high frequency (supported only by
CJ1M CPU Units Ver. 3.0 or later)
D: First Destination Word
The PV is output to D or to D and D+1.
Operand Specifications
D
D+1
0
15
DPV
0
15
Lower word of PV
Upper word of PV
2-word PV
Pulse output PV, high-speed counter input PV,
high-speed counter input frequency for high-speed counter input 0
1-word PV
Interrupt input PV in counter mode, status, range comparison results
Area P C D
CIO Area --- --- CIO 0000 to CIO 6142
Work Area --- --- W000 to W510
Holding Bit Area --- --- H000 to H510
Auxiliary Bit Area --- --- A448 to A958
Timer Area --- --- T0000 to T4094
Counter Area --- --- C0000 to C4094
DM Area --- --- D00000 to D32766
EM Area without bank --- --- ---
EM Area with bank --- --- ---
Indirect DM/EM
addresses in binary
--- --- @ D00000 to @ D32767
Indirect DM/EM
addresses in BCD
--- --- *D00000 to *D32767
Constants See descrip-
tion of oper-
and.
See descrip-
tion of oper-
and.
---
Data Registers --- --- ---
Index Registers --- --- ---
Indirect addressing
using Index Registers
--- --- ,IR0 to ,IR15
–2048 to +2047 ,IR0 to
–2048 to +2047 ,IR15
DR0 to DR15, IR0 to
IR15
,IR0+(++) to ,IR15+(++)
,–(– –)IR0 to, –(– –)IR15
