Built-in Outputs Section 7-1
Preparation
PLC Setup Settings
Note The Use Origin Operation Setting is read when the power supply is turned
ON.
DM Area Settings Starting Frequency
CX-Programmer version Tab name Setting
Ver. 3.1 or lower
Define Origin Operation
Settings Field of Define
Origin
Origin search data
Ver. 3.2 or higher Pulse Output 0 Origin search data
Setting details Address Data
X-axis starting frequency D00000 #0000
Y-axis starting frequency D00002 #0000
