Omron CJ1W-EIP21 User Manual

7-29
7 Tag Data Link Functions
CJ-series EtherNet/IP Units Operation Manual for NJ-series CPU Unit (W495)
7-2 Setting Tag Data Links
7
7-2-4 Creating Tags and Tag Sets
 Importing to the Network Configurator
Precautions for Correct UsePrecautions for Correct Use
Variables with a Network Publish attribute that have variable names that are the same as the I/O
memory address notation, such as “0000” and “H0000” are not exported to CSV files.
1) Variable names that contain only single-byte numerals (Example: 001)
2) Variable names with the following single-byte letters (uppercase or lowercase) followed by sin-
gle-byte numerals
• H (Example: H30)
• W (Example: w30)
• D (Example: D100)
• E0_ to E18_ (Example: EA_100)
1 Double-click the icon of the device registered in the Network Configurator for which you want to
import the variable with a Network Publish attribute to display the Edit Device Parameters Dialog
Box.
Right-click the icon to display the pop-up menu, and select Device
− Parameter − Edit.
2 Click the Tag Sets Tab at the top of the Edit Device Parameters Dialog Box. Select Import from
File from the To/From File Button.
A confirmation dialog box is displayed that asks you how you want to import the variables as
shown below.
• To import all variables with a Network Publish attribute, click the Yes Button. To import only
some of these variables, click the No Button.
