Omron CJ1W-EIP21 User Manual

13 Troubleshooting
13-28
CJ-series EtherNet/IP Units Operation Manual for NJ-series CPU Unit (W495)
021A Logic error in setting table 00 hex 02 hex: Network parame-
ters
03 hex: Routing tables
04 hex: Unit Setup
0E hex: Unit name
12 hex: Status area layout
setting error
13 hex: Status area layout
setting verification error
15 hex: Installation in a
PLC of another series
(e.g., from NJ to CJ2) after
setting the Unit.
Ye s
0300 Parameter error; packet discarded CIP Frame:
FFFF
No
0347 I/O refreshing error 00 hex 00 hex Yes
03C0 FINS/TCP setting error 01 to 10 hex:
Connection number
01: Automatically allo-
cated FINS node address
duplication
02: Destination IP address
error
03: Destination port num-
ber error
No
03C1 Server settings error 00 hex: DNS
03 hex: SNTP
04 hex: FTP
06 hex: BOOTP
07 hex: SNMP
08 hex: SNMP Trap
09 hex: FINS/UDP
0A hex: FINS/TCP
01: IP address
02: Host name
03: Port number
04: Other parameter
No
03C2 FINS/TCP packet discarded 01 to 10 hex:
Connection number
02 hex: Reopening
because remote node
closed
03 hex: Reopening
because of reception error
04 hex: Reopening
because of transmission
error
05 hex: Reopening
because RST received
from remote node
06 hex: Reopening
because of no keep-alive
response
07 hex: Illegal FINS/TCP
procedure
08 hex: Insufficient mem-
ory during server process-
ing
09 hex: Insufficient mem-
ory during client process-
ing
0A hex: Insufficient mem-
ory during node switching
No
Error
code
(hex)
Error
Detail code Saved in
non-volatile
memory
First byte Second byte
