13 Troubleshooting
13-30
CJ-series EtherNet/IP Units Operation Manual for NJ-series CPU Unit (W495)
* If a memory error occurs in the error log area of the non-volatile memory, the record will not be stored in the non-volatile
memory.
03D1 Ethernet advanced setting error 02 hex: FINS setting error 01 hex: Checksum error
10 hex: Invalid IP router
table
11 hex: Invalid FINS/UDP
setting
12 hex: Invalid FINS/TCP
setting
13 hex: Invalid FTP setting
14 hex: Invalid SNTP set-
ting
15 hex: Invalid SNMP set-
ting
16 hex: Invalid SNMP trap
setting
Ye s
03D2 Packet discarded. 01 hex 00 hex No
03D3 Link OFF error 00 hex 00 hex No
03D4 Verification error (Tag data link only)
Note For details on identifying the cause
of the verification error, refer to 13-
3 Connection Status Codes and
Error Processing.
This error will not be stored when a
target node is missing.
Connection instance num-
ber (0 to 255)
Lower eight bits of IP
address
No
03D5 Tag data link error 00 hex Lower eight bits of IP
address
No
0601 CPU Bus Unit error Variable Yes
0602 CPU Bus Unit memory error 01: Read error
02: Write error
02 hex: Network parame-
ter
06 hex: Error log
09 hex: Identity data
0E hex: Unit name
0F hex: Ethernet basic
setting
10 hex: Ethernet
advanced setting
11 hex: MAC address
12 hex: Status area layout
setting
14 hex: Term Tag address
resolution memory write
error
Yes *
Error
code
(hex)
Error
Detail code Saved in
non-volatile
memory
First byte Second byte
