Omron CJ1W-EIP21 User Manual

A-29
Appendices
CJ-series EtherNet/IP Units Operation Manual for NJ-series CPU Unit (W495)
A-6 Differences in Available Functions Depending on the CPU Unit (NJ or CJ Series)
App
A-6-2 Differences in Access Methods from the User Program
 CIO n+6 to n+9: Target Node PLC Error Flags
The device variable that corresponds to all of the bits in CIO n+6 to n+9 is given in the following
table.
CIO n+5 0 *_TargetPLCMdSta[48] Target Node PLC Operating Flag for Node
Address 48
1 *_TargetPLCMdSta[49] Target Node PLC Operating Flag for Node
Address 49
2 *_TargetPLCMdSta[50] Target Node PLC Operating Flag for Node
Address 50
3 *_TargetPLCMdSta[51] Target Node PLC Operating Flag for Node
Address 51
4 *_TargetPLCMdSta[52] Target Node PLC Operating Flag for Node
Address 52
5 *_TargetPLCMdSta[53] Target Node PLC Operating Flag for Node
Address 53
6 *_TargetPLCMdSta[54] Target Node PLC Operating Flag for Node
Address 54
7 *_TargetPLCMdSta[55] Target Node PLC Operating Flag for Node
Address 55
8 *_TargetPLCMdSta[56] Target Node PLC Operating Flag for Node
Address 56
9 *_TargetPLCMdSta[57] Target Node PLC Operating Flag for Node
Address 57
10 *_TargetPLCMdSta[58] Target Node PLC Operating Flag for Node
Address 58
11 *_TargetPLCMdSta[59] Target Node PLC Operating Flag for Node
Address 59
12 *_TargetPLCMdSta[60] Target Node PLC Operating Flag for Node
Address 60
13 *_TargetPLCMdSta[61] Target Node PLC Operating Flag for Node
Address 61
14 *_TargetPLCMdSta[62] Target Node PLC Operating Flag for Node
Address 62
15 *_TargetPLCMdSta[63] Target Node PLC Operating Flag for Node
Address 63
I/O memory location in CJ-
series CPU Unit
Device variable for the CJ-series Unit in NJ-series CPU Unit
Word address Bit numbers Variable name Description
CIO n+6 to
n+9
00 to 15 in
each word
*_TargetPLCErrSta Target Node PLC Error Flags
(The functions of bits 00 to 15 in these words
and the functions of the device variable given
on the left correspond as given below.)
• Bits 00 to 15 of CIO n+6 correspond to bits
00 to 15 of the device variable given on the
left.
• Bits 00 to 15 of CIO n+7 correspond to bits
16 to 31 of the device variable given on the
left.
• Bits 00 to 15 of CIO n+8 correspond to bits
32 to 47 of the device variable given on the
left.
• Bits 00 to 15 of CIO n+9 correspond to bits
48 to 63 of the device variable given on the
left.
I/O memory location in CJ-
series CPU Unit
Device variable for the CJ-series Unit in NJ-series CPU Unit
Word address Bit number Variable name Description
