Omron CJ1W-EIP21 User Manual

Appendices
A-30
CJ-series EtherNet/IP Units Operation Manual for NJ-series CPU Unit (W495)
The device variables that correspond to bits 00 to 15 in CIO n+6 to n+9 are given in the following
table.
I/O memory location in CJ-
series CPU Unit
Device variable for the CJ-series Unit in NJ-series CPU Unit
Word address Bit number Variable name Description
CIO n+6 0 *_TargetPLCErrSta[0] Target Node PLC Error Flag for Node Address 0
1 *_TargetPLCErrSta[1] Target Node PLC Error Flag for Node Address 1
2 *_TargetPLCErrSta[2] Target Node PLC Error Flag for Node Address 2
3 *_TargetPLCErrSta[3] Target Node PLC Error Flag for Node Address 3
4 *_TargetPLCErrSta[4] Target Node PLC Error Flag for Node Address 4
5 *_TargetPLCErrSta[5] Target Node PLC Error Flag for Node Address 5
6 *_TargetPLCErrSta[6] Target Node PLC Error Flag for Node Address 6
7 *_TargetPLCErrSta[7] Target Node PLC Error Flag for Node Address 7
8 *_TargetPLCErrSta[8] Target Node PLC Error Flag for Node Address 8
9 *_TargetPLCErrSta[9] Target Node PLC Error Flag for Node Address 9
10 *_TargetPLCErrSta[10] Target Node PLC Error Flag for Node Address 10
11 *_TargetPLCErrSta[11] Target Node PLC Error Flag for Node Address 11
12 *_TargetPLCErrSta[12] Target Node PLC Error Flag for Node Address 12
13 *_TargetPLCErrSta[13] Target Node PLC Error Flag for Node Address 13
14 *_TargetPLCErrSta[14] Target Node PLC Error Flag for Node Address 14
15 *_TargetPLCErrSta[15] Target Node PLC Error Flag for Node Address 15
CIO n+7 0 *_TargetPLCErrSta[16] Target Node PLC Error Flag for Node Address 16
1 *_TargetPLCErrSta[17] Target Node PLC Error Flag for Node Address 17
2 *_TargetPLCErrSta[18] Target Node PLC Error Flag for Node Address 18
3 *_TargetPLCErrSta[19] Target Node PLC Error Flag for Node Address 19
4 *_TargetPLCErrSta[20] Target Node PLC Error Flag for Node Address 20
5 *_TargetPLCErrSta[21] Target Node PLC Error Flag for Node Address 21
6 *_TargetPLCErrSta[22] Target Node PLC Error Flag for Node Address 22
7 *_TargetPLCErrSta[23] Target Node PLC Error Flag for Node Address 23
8 *_TargetPLCErrSta[24] Target Node PLC Error Flag for Node Address 24
9 *_TargetPLCErrSta[25] Target Node PLC Error Flag for Node Address 25
10 *_TargetPLCErrSta[26] Target Node PLC Error Flag for Node Address 26
11 *_TargetPLCErrSta[27] Target Node PLC Error Flag for Node Address 27
12 *_TargetPLCErrSta[28] Target Node PLC Error Flag for Node Address 28
13 *_TargetPLCErrSta[29] Target Node PLC Error Flag for Node Address 29
14 *_TargetPLCErrSta[30] Target Node PLC Error Flag for Node Address 30
15 *_TargetPLCErrSta[31] Target Node PLC Error Flag for Node Address 31
CIO n+8 0 *_TargetPLCErrSta[32] Target Node PLC Error Flag for Node Address 32
1 *_TargetPLCErrSta[33] Target Node PLC Error Flag for Node Address 33
2 *_TargetPLCErrSta[34] Target Node PLC Error Flag for Node Address 34
3 *_TargetPLCErrSta[35] Target Node PLC Error Flag for Node Address 35
4 *_TargetPLCErrSta[36] Target Node PLC Error Flag for Node Address 36
5 *_TargetPLCErrSta[37] Target Node PLC Error Flag for Node Address 37
6 *_TargetPLCErrSta[38] Target Node PLC Error Flag for Node Address 38
7 *_TargetPLCErrSta[39] Target Node PLC Error Flag for Node Address 39
8 *_TargetPLCErrSta[40] Target Node PLC Error Flag for Node Address 40
9 *_TargetPLCErrSta[41] Target Node PLC Error Flag for Node Address 41
10 *_TargetPLCErrSta[42] Target Node PLC Error Flag for Node Address 42
11 *_TargetPLCErrSta[43] Target Node PLC Error Flag for Node Address 43
12 *_TargetPLCErrSta[44] Target Node PLC Error Flag for Node Address 44
13 *_TargetPLCErrSta[45] Target Node PLC Error Flag for Node Address 45
14 *_TargetPLCErrSta[46] Target Node PLC Error Flag for Node Address 46
15 *_TargetPLCErrSta[47] Target Node PLC Error Flag for Node Address 47
