A-33
Appendices
CJ-series EtherNet/IP Units Operation Manual for NJ-series CPU Unit (W495)
A-6 Differences in Available Functions Depending on the CPU Unit (NJ or CJ Series)
App
A-6-2 Differences in Access Methods from the User Program
 CIO n+13: Communications Status 2
The device variable that corresponds to all of the bits in CIO n+13 is given in the following table.
The device variables that correspond to bits 00 to 15 in CIO n+13 are given in the following table.
 CIO n+14: Communications Status 3
The device variable that corresponds to all of the bits in CIO n+14 is given in the following table.
The device variables that correspond to bits 00 to 15 in CIO n+14 are given in the following table.
I/O memory location in CJ-
series CPU Unit
Device variable for the CJ-series Unit in NJ-series CPU Unit
Word address Bit numbers Variable name Description
CIO n+13 00 to 15 *_CommSta2 Communications Status 2
(The functions of bits 00 to 15 in CIO n+13
correspond to the functions of bits 00 to 15 of
the device variable given on the left.)
I/O memory location in CJ-
series CPU Unit
Device variable for the CJ-series Unit in NJ-series CPU Unit
Word address Bit numbers Variable name Description
CIO n+13 0 *_FTPSta FTP Status
01 to 13 --- Not used.
14 *_LkSta Link Status
15 --- Not used.
I/O memory location in CJ-
series CPU Unit
Device variable for the CJ-series Unit in NJ-series CPU Unit
Word address Bit numbers Variable name Description
CIO n+14 00 to 15 *_CommSta3 Communications Status 3
(The functions of bits 00 to 15 in CIO n+14
correspond to the functions of bits 0 to 15 of
the device variable given on the left.)
I/O memory location in CJ-
series CPU Unit
Device variable for the CJ-series Unit in NJ-series CPU Unit
Word address Bit numbers Variable name Description
CIO n+14 00 and 01 --- Not used.
2 *_ETNBaseSetErr Basic Ethernet Settings Error
3 *_IPAdrTblErr IP Address Table Error
4 *_IPRouterTblErr IP Router Table Error
5 *_DNSSvrErr DNS Server Error
6 *_RTblErr Routing Table Error
07 and 08 --- Not used.
9 *_ETNAdvSetErr Ethernet Advanced Settings Error
10 *_BootpSvrErr BOOTP Server Error
11 *_SNTPSvrErr SNTP Server Error
12 and 13 --- Not used.
14 *_AdrMismatchErr Address Mismatch
15 *_MemErr Non-volatile Memory Error
