Appendices
A-34
CJ-series EtherNet/IP Units Operation Manual for NJ-series CPU Unit (W495)
CIO n+16 to n+19: Registered Target Node Table
The device variable that corresponds to all of the bits in CIO n+16 to n+19 is given in the following
table.
The device variables that correspond to bits 00 to 15 in CIO n+16 to n+19 are given in the following
table.
I/O memory location in CJ-
series CPU Unit
Device variable for the CJ-series Unit in NJ-series CPU Unit
Word address Bit numbers Variable name Description
CIO n+16 to
n+19
00 to 15 in
each word
*_RegTargetSta Registered Target Node Table
(The functions of bits 00 to 15 in these words and
the functions of the device variable given on the left
correspond as given below.)
Bits 00 to 15 of CIO n+16 correspond to bits 00 to
15 of the device variable given on the left.
Bits 00 to 15 of CIO n+17 correspond to bits 16 to
31 of the device variable given on the left.
Bits 00 to 15 of CIO n+18 correspond to bits 32 to
47 of the device variable given on the left.
Bits 00 to 15 of CIO n+19 correspond to bits 48 to
63 of the device variable given on the left.
I/O memory location in CJ-
series CPU Unit
Device variable for the CJ-series Unit in NJ-series CPU Unit
Word address Bit numbers Variable name Description
CIO n+16 0 *_RegTargetSta[0] Registered Target Node Table Bit for Node Address
0
1 *_RegTargetSta[1] Registered Target Node Table Bit for Node Address
1
2 *_RegTargetSta[2] Registered Target Node Table Bit for Node Address
2
3 *_RegTargetSta[3] Registered Target Node Table Bit for Node Address
3
4 *_RegTargetSta[4] Registered Target Node Table Bit for Node Address
4
5 *_RegTargetSta[5] Registered Target Node Table Bit for Node Address
5
6 *_RegTargetSta[6] Registered Target Node Table Bit for Node Address
6
7 *_RegTargetSta[7] Registered Target Node Table Bit for Node Address
7
8 *_RegTargetSta[8] Registered Target Node Table Bit for Node Address
8
9 *_RegTargetSta[9] Registered Target Node Table Bit for Node Address
9
10 *_RegTargetSta[10] Registered Target Node Table Bit for Node Address
10
11 *_RegTargetSta[11] Registered Target Node Table Bit for Node Address
11
12 *_RegTargetSta[12] Registered Target Node Table Bit for Node Address
12
13 *_RegTargetSta[13] Registered Target Node Table Bit for Node Address
13
14 *_RegTargetSta[14] Registered Target Node Table Bit for Node Address
14
15 *_RegTargetSta[15] Registered Target Node Table Bit for Node Address
15
