A-39
Appendices
CJ-series EtherNet/IP Units Operation Manual for NJ-series CPU Unit (W495)
A-6 Differences in Available Functions Depending on the CPU Unit (NJ or CJ Series)
App
A-6-2 Differences in Access Methods from the User Program
CIO n+24: FINS/TCP Connection Status
The device variable that corresponds to all of the bits in CIO n+24 is given in the following table.
CIO n+22 12 *_EstbRegTargetSta[44] Normal Target Node Table Bit for Node Address
44
13 *_EstbRegTargetSta[45] Normal Target Node Table Bit for Node Address
45
14 *_EstbRegTargetSta[46] Normal Target Node Table Bit for Node Address
46
15 *_EstbRegTargetSta[47] Normal Target Node Table Bit for Node Address
47
CIO n+23 0 *_EstbRegTargetSta[48] Normal Target Node Table Bit for Node Address
48
1 *_EstbRegTargetSta[49] Normal Target Node Table Bit for Node Address
49
2 *_EstbRegTargetSta[50] Normal Target Node Table Bit for Node Address
50
3 *_EstbRegTargetSta[51] Normal Target Node Table Bit for Node Address
51
4 *_EstbRegTargetSta[52] Normal Target Node Table Bit for Node Address
52
5 *_EstbRegTargetSta[53] Normal Target Node Table Bit for Node Address
53
6 *_EstbRegTargetSta[54] Normal Target Node Table Bit for Node Address
54
7 *_EstbRegTargetSta[55] Normal Target Node Table Bit for Node Address
55
8 *_EstbRegTargetSta[56] Normal Target Node Table Bit for Node Address
56
9 *_EstbRegTargetSta[57] Normal Target Node Table Bit for Node Address
57
10 *_EstbRegTargetSta[58] Normal Target Node Table Bit for Node Address
58
11 *_EstbRegTargetSta[59] Normal Target Node Table Bit for Node Address
59
12 *_EstbRegTargetSta[60] Normal Target Node Table Bit for Node Address
60
13 *_EstbRegTargetSta[61] Normal Target Node Table Bit for Node Address
61
14 *_EstbRegTargetSta[62] Normal Target Node Table Bit for Node Address
62
15 *_EstbRegTargetSta[63] Normal Target Node Table Bit for Node Address
63
I/O memory location in CJ-
series CPU Unit
Device variable for the CJ-series Unit in NJ-series CPU Unit
Word address Bit numbers Variable name Description
CIO n+24 00 to 15 *_FINSTCPConnSta FINS/TCP Connection Status
(The functions of bits 00 to 15 in CIO n+24
correspond to the functions of bits 0 to 15 of
the device variable given on the left.)
I/O memory location in CJ-
series CPU Unit
Device variable for the CJ-series Unit in NJ-series CPU Unit
Word address Bit numbers Variable name Description
