Appendices
A-40
CJ-series EtherNet/IP Units Operation Manual for NJ-series CPU Unit (W495)
The device variables that correspond to bits 00 to 15 in CIO n+24 are given in the following table.
 Words m+98 and m+99: IP Address Display/Setting Area
The device variable that corresponds to all of the bits in words m+98 and m+99 is given in the follow-
ing table.
The device variables that correspond to bits 00 to 15 in words m+98 and m+99 are given in the fol-
lowing table.
IP address fields: 1.2.3.4 (hex)
I/O memory location in CJ-
series CPU Unit
Device variable for the CJ-series Unit in NJ-series CPU Unit
Word address Bit number Variable name Description
CIO n+24 0 *_FINSTCPConnSta1 FINS/TCP Connection Status for Connection 1
1 *_FINSTCPConnSta2 FINS/TCP Connection Status for Connection 2
2 *_FINSTCPConnSta3 FINS/TCP Connection Status for Connection 3
3 *_FINSTCPConnSta4 FINS/TCP Connection Status for Connection 4
4 *_FINSTCPConnSta5 FINS/TCP Connection Status for Connection 5
5 *_FINSTCPConnSta6 FINS/TCP Connection Status for Connection 6
6 *_FINSTCPConnSta7 FINS/TCP Connection Status for Connection 7
7 *_FINSTCPConnSta8 FINS/TCP Connection Status for Connection 8
8 *_FINSTCPConnSta9 FINS/TCP Connection Status for Connection 9
9 *_FINSTCPConnSta10 FINS/TCP Connection Status for Connection 10
10 *_FINSTCPConnSta11 FINS/TCP Connection Status for Connection 11
11 *_FINSTCPConnSta12 FINS/TCP Connection Status for Connection 12
12 *_FINSTCPConnSta13 FINS/TCP Connection Status for Connection 13
13 *_FINSTCPConnSta14 FINS/TCP Connection Status for Connection 14
14 *_FINSTCPConnSta15 FINS/TCP Connection Status for Connection 15
15 *_FINSTCPConnSta16 FINS/TCP Connection Status for Connection 16
DM Area Words Allocated to CPU Bus Units
I/O memory location in CJ-
series CPU Unit
Device variable for the CJ-series Unit in NJ-series CPU Unit
Word address Bit numbers Variable name Description
Words m+98
and m+99
00 to 15 *_IPAdrCfg IP Address Display/Setting Area
I/O memory location in
CJ-series CPU Unit
Device variable for the CJ-series Unit in NJ-series CPU Unit
Word
address
Bit num-
bers
Variable name Description
Word m+98 00 to 03 *_IPAdr2Cfg IP Address 2 (This is field 2 shown below.)
04 to 07
08 to 11 *_IPAdr1Cfg IP Address 1 (This is field 1 shown below.)
12 to 15
Word m+99 00 to 03 *_IPAdr4Cfg IP Address 4 (This is field 4 shown below.)
04 to 07
08 to 11 *_IPAdr3Cfg IP Address 3 (This is field 3 shown below.)
12 to 15
