Omron CJ1W-EIP21 User Manual

Appendices
A-52
CJ-series EtherNet/IP Units Operation Manual for NJ-series CPU Unit (W495)
 Words x+48 to x+63: Target Node PLC Error Flags
The device variable that corresponds to all of the bits in words x+48 to x+63 is given in the following
table.
I/O memory location in CJ-
series CPU Unit
Device variable for the CJ-series Unit in NJ-series CPU Unit
Word address Bit numbers Variable name Description
Words x+48 to
x+63
00 to 15 in
each word
*_x.TargetPLCErrSta.
TargetStaWd
Target Node PLC Error Flags
(The functions of bits 00 to 15 in these words and
the functions of the device variable given on the
left correspond as given below.)
• Bits 00 to 15 of word x+48 correspond to bits 00
to 15 of the device variable given on the left.
• Bits 00 to 15 of word x+49 correspond to bits 16
to 31 of the device variable given on the left.
• Bits 00 to 15 of word x+50 correspond to bits 32
to 47 of the device variable given on the left.
• Bits 00 to 15 of word x+51 correspond to bits 48
to 63 of the device variable given on the left.
• Bits 00 to 15 of word x+52 correspond to bits 64
to 79 of the device variable given on the left.
• Bits 00 to 15 of word x+53 correspond to bits 80
to 95 of the device variable given on the left.
• Bits 00 to 15 of word x+54 correspond to bits 96
to 111 of the device variable given on the left.
• Bits 00 to 15 of word x+55 correspond to bits
112 to 127 of the device variable given on the
left.
• Bits 00 to 15 of word x+56 correspond to bits
128 to 143 of the device variable given on the
left.
• Bits 00 to 15 of word x+57 correspond to bits
144 to 159 of the device variable given on the
left.
• Bits 00 to 15 of word x+58 correspond to bits
160 to 175 of the device variable given on the
left.
• Bits 00 to 15 of word x+59 correspond to bits
176 to 191 of the device variable given on the
left.
• Bits 00 to 15 of word x+60 correspond to bits
192 to 207 of the device variable given on the
left.
• Bits 00 to 15 of word x+61 correspond to bits
208 to 223 of the device variable given on the
left.
• Bits 00 to 15 of word x+62 correspond to bits
224 to 239 of the device variable given on the
left.
• Bits 00 to 15 of word x+63 correspond to bits
240 to 255 of the device variable given on the
left.
