CJ-series EtherNet/IP Units Operation Manual for NJ-series CPU Unit (W495)
A-6 Differences in Available Functions Depending on the CPU Unit (NJ or CJ Series)
App
A-6-2 Differences in Access Methods from the User Program
The device variables that correspond to bits 00 to 15 in words x+48 to x+63 are given in the following
table.
I/O memory location in CJ-
series CPU Unit
Device variable for the CJ-series Unit in NJ-series CPU Unit
Word address Bit number Variable name Description
Word x+48 0 *_x.TargetPLCErrSta.
TargetSta[0]
Target Node PLC Error Flag for Node Address 0
.
.
.
.
.
.
.
.
.
15 *_x.TargetPLCErrSta.
TargetSta[15]
Target Node PLC Error Flag for Node Address
15
Word x+49 0 *_x.TargetPLCErrSta.
TargetSta[16]
Target Node PLC Error Flag for Node Address
16
.
.
.
.
.
.
.
.
.
15 *_x.TargetPLCErrSta.
TargetSta[31]
Target Node PLC Error Flag for Node Address
31
Word x+50 0 *_x.TargetPLCErrSta.
TargetSta[32]
Target Node PLC Error Flag for Node Address
32
.
.
.
.
.
.
.
.
.
15 *_x.TargetPLCErrSta.
TargetSta[47]
Target Node PLC Error Flag for Node Address
47
Word x+51 0 *_x.TargetPLCErrSta.
TargetSta[48]
Target Node PLC Error Flag for Node Address
48
.
.
.
.
.
.
.
.
.
15 *_x.TargetPLCErrSta.
TargetSta[63]
Target Node PLC Error Flag for Node Address
63
Word x+52 0 *_x.TargetPLCErrSta.
TargetSta[64]
Target Node PLC Error Flag for Node Address
64
.
.
.
.
.
.
.
.
.
15 *_x.TargetPLCErrSta.
TargetSta[79]
Target Node PLC Error Flag for Node Address
79
Word x+53 0 *_x.TargetPLCErrSta.
TargetSta[80]
Target Node PLC Error Flag for Node Address
80
.
.
.
.
.
.
.
.
.
15 *_x.TargetPLCErrSta.
TargetSta[95]
Target Node PLC Error Flag for Node Address
95
Word x+54 0 *_x.TargetPLCErrSta.
T
argetSta[96]
Target Node PLC Error Flag for Node Address
96
.
.
.
.
.
.
.
.
.
15 *_x.TargetPLCErrSta.
TargetSta[111]
Target Node PLC Error Flag for Node Address
111
