Omron CJ2M-CPU Series Connection Guide

9
．
Program
39
9. Program
This section describes the details on the program used in this document.
9.1. Overview
The following explains specifications and functions of the program that are used to check the
connection between Oriental Motor Driver (hereinafter referred to as Destination Device) and
PLC (Serial Communications Unit (hereinafter referred to as SCU)).
This program performs Modbus-RTU communication by the CMND instruction (by using the
Serial Gateway function for SCU) to send and receive the command for reading "Direct I/O
and electromagnetic brake status" and detects a normal end or an error end.
A normal end of the send/receive processing means a normal end of the CMND instruction.
An error end means an error end of the CMND instruction and an error of Destination Device
(detected with the response data from Destination Device).
Here, the "&" prefix is added to decimal data and the "#" prefix is added to hexadecimal data
when it is necessary to distinguish between decimal and hexadecimal data. (e.g., "&1000" for
decimal data and "#03E8" for hexadecimal data)
Additional Information
OMRON has confirmed that normal communications can be performed using this program
under 5.2. Device Configuration, however, we do not guarantee the normal operation under
the disturbance such as electrical noise or the performance variation of the device.

Omron CJ2M-CPU Series Specifications

General

Power Supply	24 VDC
Number of Instructions	Over 400 instructions
Model	CJ2M-CPU11, CJ2M-CPU12, CJ2M-CPU13, CJ2M-CPU14, CJ2M-CPU15
Program Capacity	5K steps to 60K steps
I/O Capacity	Up to 2, 560 points
Communication Ports	Ethernet, USB, RS-232C
Execution Time	0.04 µs per basic instruction
Operating Temperature	0 to 55°C
Position Control	Supported
High-speed Counter	100 kHz max.
Pulse Output	100 kHz max.
Maximum Units	40 units
Storage Temperature	-20 to 75°C
Interrupt Inputs	Supported
