Omron CJ2M-CPU Series Connection Guide

9
．
Program
51
No. Outline Description
1.2. Control word setting
for CMND instruction
Sets the control word of CMND instruction.
For details on the settings, refer to 9.2.2. Detailed
Description of the Function.
1.3. Send/receive
symbol setting
The FINS command and the Destination Device function are
set to the send symbol, and the receive data storage area is
initialized.

Omron CJ2M-CPU Series Specifications

General

Power Supply	24 VDC
Number of Instructions	Over 400 instructions
Model	CJ2M-CPU11, CJ2M-CPU12, CJ2M-CPU13, CJ2M-CPU14, CJ2M-CPU15
Program Capacity	5K steps to 60K steps
I/O Capacity	Up to 2, 560 points
Communication Ports	Ethernet, USB, RS-232C
Execution Time	0.04 µs per basic instruction
Operating Temperature	0 to 55°C
Position Control	Supported
High-speed Counter	100 kHz max.
Pulse Output	100 kHz max.
Maximum Units	40 units
Storage Temperature	-20 to 75°C
Interrupt Inputs	Supported
