A-2
Dimensions
Dimensions are shown below. The unit of dimension is millimeters.
A-2-1
CPU Unit
8090
63.2
8090
63.2
Appendices
A-3
CK3M-series Programmable Multi-Axis Controller User's Manual Hardware (O036)
A-2 Dimensions
A
A-2-1 CPU Unit
