2-3

Ethernet Network Configuration

The Ethernet communications port on the CK3M-series CPU Unit supports the Modbus-TCP protocol.

It can be connected to devices such as PLCs and programmable terminals that support the Modbus-

TCP protocol.

HMI

NJ-series

CK3M-series

Ethernet

Built-in EtherNet/IP port

Power Supply Unit

CPU Unit

Ethernet switch

2 System Configuration

2-6

CK3M-series Programmable Multi-Axis Controller User's Manual Hardware (O036)
