A-2-4
CK3W-MD and CK3W-AD Units
CK3W-MD Unit
31.6
90 80
CK3W-AD Unit
31.6
90 80
Appendices
A-5
CK3M-series Programmable Multi-Axis Controller User's Manual Hardware (O036)
A-2 Dimensions
A
A-2-4 CK3W-MD and CK3W-AD Units
