Omron CK5M-CPU 1 Series Connection Guide

2-1
Target Device
The devices to be used in this guide are as follows.
Manufacturer Name Model
OMRON CK3E-series Programmable Multi-Axis Controller
CK3E-££££
OMRON CK3M/CK5M-series Programmable Multi-Axis Controller
CK5M-CPU1£1
CK3M-CPU1£1
OMRON NJ/NX-series CPU Unit
NX701-££££
NX102-££££
NX1P2-££££££
NJ501-££££
NJ301-££££
NJ101-££££
OMRON Industrial Switching Hub
W4S1-0££
Precautions for Correct Use
The connection procedures and confirmation methods in this document use the models and
versions of devices described in 2-2 Device Configuration on page 2-3 among the above tar-
get devices.
You cannot use devices whose versions are older than those listed in 2-2 Device Configuration
on page 2-3.
To use models that are not listed in 2-2 Device Configuration on page 2-3 among the above
target devices, or devices whose versions are newer than those listed in 2-2 Device Configura-
tion on page 2-3, check their manuals or user’s guides to confirm differences in the specifica-
tions before use.
Additional Information
This document provides the connection procedures to establish communications. It does not
provide information other than the connection procedures, such as the operation, installation,
wiring, and functions and motions of the devices. Refer to the relevant manuals or user’s
guides, or contact your OMRON representative.
2 Target Device and System Configuration
2-2
CK3E/CK3M/CK5M Series EtherNet/IP Connection Guide (O903)

Omron CK5M-CPU 1 Series Specifications

General

Brand	Omron
Model	CK5M-CPU 1 Series
Category	Controller
Language	English
