4
In the Solution Explore, right-click the
project name and select Build and
Download All Programs to build and
download all programs.
After the download is completed, make
sure that there are no errors in the Out-
put tab page.
5
Saving the downloaded settings and
programs
After the download is completed and
you make sure that there are no errors
in the Output tab page, execute the
save command from the Terminal.
• By executing the save command, the
downloaded project is stored in the
PMAC. Use this operation to save
the settings that are executed auto-
matically when the power supply to
the PMAC is turned ON.
6
Restarting the PMAC after download
Execute the $$$ command from the
T
erminal and use the downloaded
project to restart the PMAC.
Appendices
A-3
CK3E/CK3M/CK5M Series EtherNet/IP Connection Guide (O903)
A-1 Saving and Reading the Project
A
A-1-2 Reading and Downloading the Project
