Specifications
13
CPM1A-DRT21 DeviceNet I/O Link Unit
By connecting the DeviceNet I/O Link Unit (CPM1A-DRT21), the CPM2A can function as the slave of a DeviceNet D Master Unit. In
this configuration, I/O links for up to 32 inputs and 32 outputs can be created.
Specifications
Item Specification
Master/slave DeviceNet slave
Model number CPM1A-DRT21
Number of I/O points between
Unit and Master
Input: 32 points
Output: 32 points
Number of words allocated
from CPM2A’s I/O memory
Input: 2 words
Output: 2 words
(Allocated in the same way as other Expansion Units.)
Node address setting method Set using DIP switch.
Maximum number of
connectable nodes
63 (CS1)
32 (CVM1/CV)
25 (C200HX/HG/HE)
16 (C200HS)
(The series names in parentheses are for the CPU Unit to which the Master Unit is mounted.)
Temperature Sensor Units
By mounting a Temperature Sensor Unit (CPM1A-TS001/TS002/TS101/TS102) to the PC, input can be obtained from a thermocou-
ple or platinum resistance thermometer,and temperature measurements can be converted to binary data (4-digit hexadecimal) and
stored in the input area of the CPU Unit. For details on the maximum number of connectable Units, refer to 7.
Specifications
Item Specification
Model number CPM1A-TS001/002 CPM1A-TS101/102
Number of inputs 2 (TS001), 4 (TS002) 2 (TS101), 4 (TS102)
Input types K, J switchable
(Note: Same input for all input points.)
Pt100, JPt100 switchable
(Note: Same input for all input points.)
Indication accuracy [The larger of the indicated value ±0.5% and
±2°C] ±1 digit max.
[The larger of the indicated value ±0.5% and
±1°C] ±1 digit max.
Conversion time 250 ms/2 points (TS001, TS101); 250 ms/4 points (TS002, TS102)
Converted temperature data Binary (4-digit hexadecimal)
Isolation method Photocoupler isolation between the temperature input signals.
Note: The indication accuracy when using a K-type thermocouple for temperatures less than –100°C is ±4°C ±1 digit max.
Input Temperature Ranges for CPM1A-TS001/002
The rotary switch can be used to make of the following range and input type settings for CPM1A-TS001/002 models.
Input type
Range (°C) Range (°F)
K
–200 to 1300 –300 to 2300
0.0 to 500.0 0.0 to 900.0
J
–100 to 850 –100 to 1500
0.0 to 400.0 0.0 to 750.0
Input Temperature Ranges for CPM1A-TS101/102
The rotary switch can be used to make of the following range and input type settings for CPM1A-TS101/102 models.
Input type
Range (°C) Range (°F)
Pt100 –200.0 to 650.0 –300 to 1200.0
JPt100 –200.0 to 650.0 –300 to 1200.0
