Programmable Controllers
This catalog contains information necessary
to select models.
It does not include precautionary information.
Please refer to the CPM1A manuals for
the required information.
The Smallest PLC in the SYSMAC Fam ily Shows
Just How Far Downsizing Can Go
The 10-point CPU is
approximately the size of a PC Card.
The SYSMAC C Series began developing a
wide range of Programmable Controllers to
meet factory automation needs in 1973.
And now the CPM1A joins the C Series
history as a small PLC that has all the
power of previous small PLCs but requires
far less mounting space. The CPM1A also
provides flexibility in I/O capacity ranging
from 10 to 100 I/O points. The CPM1A can
replace relay control, help distribute I/O,
work as a miniature machine controller or
sensor controller, or fill many other vital
roles in factory automation.
90mm 85.6mm
Contents
System Configuration
CPM1A Line-up
CPM1A System Configuration
External Dimensions
Specifications
General Specifications
Power Consumption for DC Models
Performance Specifications
I/O Specifications
CPM1A-DRT21 DeviceNet I/O Link Unit
Temperature Sensor Units
Communications Adapter
Specifications CPM1-CIF01/CIF11
CPM2C-PA201 AC Power Supply Unit
Functions
Input Interrupts
Quick-response Inputs
High-speed Counter
Interval Timer Interrupts
Analog Setting
Pulse Output Function
Communications
Programming Instructions
Peripheral Devices
Standard Models
Expansion Memory Unit
