Omron CPM1A - System Configuration; CPM1 A Line-Up

6
CPM1A Line-up
CPU with AC Power Supply • DC input • RY output / TR output
10 I/O points
(Expansion
not possible)
30 I/O points 40 I/O points
20 I/O points
CPM1-CIF01
RS-232C Adapter
CPM1-CIF11
RS-422 Adapter
20 I/O points
(Expansion
not possible)
CPU with DC Power Supply • DC input • RY output / TR output
Expansion I/O Unit
• DC input
• RY output / TR output
Expansion I/O Unit
• DC input
CompoBus/S
I/O Link Unit
Analog I/O Unit
• RY output / TR output
CPM1A-SRT21 CPM1A-MAD01
-MAD11
Temperature
Sensor Units
CPM1A-TS001
TS002
TS101
TS102
DeviceNet I/O
Link Unit
CPM1A-DRT21
System Configuration
