Specifications
14
Communications Adapter Specifications CPM1-CIF01/CIF11
RS-232C Adapter and RS-422 Adapter
Item
Specifications
CPM1-CIF01 CPM1-CIF11
Functions Level conversion between the CMOS level (CPU side)
and the RS-232C (peripheral device side)
Level conversion between the CMOS level (CPU side)
and the RS-422 (peripheral device side)
Insulation The RS-232C (peripheral device side) is insulated by a
DC/DC converter and photocoupler.
The RS-422 (peripheral device side) is insulated by a
DC/DC converter and photocoupler.
Power supply Power is supplied by the CPU.
Power consumption 0.3 A max.
Transmission speed 38.4 Kbits/s max.
Vibration resistance 10 to 57 Hz with an amplitude of 0.075 mm, and 57 to 150 Hz with an acceleration of 9.8 m/s
2
in the X, Y and Z
directions for 80 minutes each in accordance (i.e. swept for 8 minutes, 10 times).
Shock resistance 147 m/s
2
in the X, Y and Z directions 3 times each.
Ambient temperature
(operating)
0° to 55°C
Ambient humidity
(operating)
10% to 90% (with no condensation)
Ambient environment
(operating)
With no corrosive gas
Ambient temperature
(storage)
–20° to 75°C
Weight 200 g max.
Memory Backup
The user program and memory area data in the CPU Unit are backed up by either one of the following methods.
• Flash Memory:
User program, read-only DM area (DM 6144 to DM 6599), and PC Setup area (DM 6600 to DM 6655).
• Internal Capacitor:
DM areas other than the above, HR area, AR area, and
Counter area.
The capacitor provides backup for a power interruption lasting
20 days at room temperature. If the power is expected to remain
OFF for a period exceeding this data backup period, consider-
ation must be given to the design of the system so that no prob-
lems will occur when the set values become undefined ones. For
further details, refer to CPM1A Operation Manual (W317).
Capacitor backup time (days)
Ambient temperature (_C)
20
10
7
1
25 40 80
