Omron CS1W User Manual

System Configuration
19
Using a XW2Z-200S-CV/500S-CV or XW2Z-200S-V/500S-V Cable for an RS-232C
Connection
Peripheral port
D-sub Connector
(9-pin female)
XW2Z-200S-CV/500S-CV
or
XW2Z-200S-V/500S-V
(See note.)
D-sub Connector
(9-pin male)
D-sub Connector (9-pin male)
D-sub Connector
(
9-
p
in female
)
CS/CJ-series peripheral connecto
r
CS1W-CN118
CQM1H PLC connection
CPM2C PLC connection
CS1W-CIF31
USB type A plug, male
Note: With a CS/CJ-series PLC, the connection must be a host link connection.
• Connecting to the RS-232C Port
Using a XW2Z-200S-CV/500S-CV or XW2Z-200S-V/500S-V Cable for an RS-232C
Connection
RS-232C port
D-sub Connector
(9-pin female)
D-sub Connector
(9-pin female)
XW2Z-200S-CV/500S-CV
or
XW2Z-200S-V/500S-V
(See note.)
D-sub Connector
(9-pin male)
D-sub Connector
(9-pin male)
CQM1H PLC connection
CPM2C PLC connection
CS1W-CIF31
USB type A plug, male
Note: With a CS/CJ-series PLC, the connection must be a host link connection.
