131
Advanced Function Setting Level Section 5-7
Multi-SP is a function for setting set points 0 to 3 in advance, and switching
between these set points using the ON/OFF combinations of event inputs 1
and 2.
The “number of multi-SP uses” parameter is used when the number of preset
set points is either two or four.
This parameter determines whether the “event input assignment 1” and
“event input assignment 2” parameters are displayed.
The “number of multi-SP uses” parameter displays which functions are
assigned to event inputs 1 and 2.
Note If the “number of multi-SP uses” parameter is set to 0, both input assign-
ments 1 and 2 can be set. Once “STOP” (RUN/STOP), or “MANU” (auto/
manual) has been assigned to one event input, the other event can be
assigned only to either of the remaining two settings.
Default: 1
Multi-SP switching by event inputs can be used with Controllers that have
event inputs, when the “number of multi-SP uses” parameter is set to 1 or 2.
The following tables show the relationships between ON/OFF combinations of
event inputs 1 and 2 and selected set points.
Number of Multi-SP Uses: 1
Number of Multi-SP Uses: 2
Note Event inputs can be used on the following Controllers. E5CZ-@2M@@ with
E53-CZB or E53-CZHB,E5AZ-@3@M@@ with E53-AZB,E5EZ-@3@M@@
with E53-AZB.Turn the event inputs ON or OFF while the power is turned
ON. Event input ON/OFF changes are detected for inputs of 50 ms or longer.
ev-m Number of Multi-SP Uses
Event inputs must be supported.
Settings Event inputs
Event input
assignment 1
Event input
assignment 2
Function of
event input 1
Function of
event input 2
Number of
multi-SP
uses
0 (See
note. )
NONE, STOP, MANU None, or switching RUN/
STOP, or auto/manual
1(Not dis-
played.)
NONE, STOP,
MANU
Multi-SP, 2
points (switch-
ing set points
0 and 1)
None, or
switching
RUN/STOP,
or auto/man-
ual
2 (Not displayed.) Multi-SP, 4 points (switching
set points 0, 1, 2, 3)
Function
Setting
Event input 1 Selected set point
OFF Set point 0
ON Set point 1
Event input 1 Event input 2 Selected set point
OFF OFF Set point 0
ON OFF Set point 1
OFF ON Set point 2
ON ON Set point 3
